Inteli-Power RV converter/charger PD9360V 9300 Series — 60A, multi-chemistry deck-mount

The Inteli-Power PD9360V 9300 Series is a 60‑amp deck‑mount RV converter/charger that selects and stores charging profiles for Flooded, AGM, LiFePO4 or fixed 13.6 VDC output to protect and maintain your service batteries.

This compact converter from Inteli-Power brings flexible, multi‑chemistry charging to your RV electrical system so you don’t have to swap hardware when you change battery types. It accepts 105–130 VAC input and delivers 60 amps between 13.6 and 14.7 VDC depending on the selected profile. The unit stores your choice in memory and offers automatic switches between charge, boost/absorption and float or idle stages to keep batteries topped without constant adjustment.

How does the PD9360V manage different battery chemistries?

The converter uses a simple mode button and color LEDs to let you pick Flooded Lead Acid (FLA), Absorbed Glass Mat (AGM), Lithium Iron Phosphate (LiFePO4) or a fixed 13.6 VDC output. Once selected, that profile is saved in memory so the charger applies the correct voltage and staging every time it powers up.

• FLA mode: default green LED, auto BOOST to ~14.4 V when needed
• LiFePO4 mode: blue LED, nominal 14.4 V then drops to 13.6 V when current falls
• AGM mode: white LED, nominal 14.0 V with timed absorption to 14.7 V then float
• Magenta mode: constant 13.6 V output for fixed voltage applications

What protections and automatic behaviors does it provide?

The PD9360V includes automatic transitions between charging stages and a storage routine to reduce battery degradation when batteries sit unused. It will switch to boost, absorption, float, idle or storage based on voltage and current thresholds to prevent overcharge and help maintain battery health.

• Automatic BOOST when battery voltage drops below preset levels
• Idle/float switching when charge current falls below thresholds
• Storage mode after extended inactivity to lower voltage and reduce stress
• Automatic 15‑minute periodic equalization-like pulse while in storage to limit sulfation

How do you change modes and what cautions should you follow?

Changing the charging profile is done by pressing and holding the mode button until the LED changes color, and continuing until your chosen color appears. The selection is then retained. Follow chemistry-specific cautions: never recharge Flooded Lead Acid batteries while in Lithium or AGM modes.

• Press and hold MODE for 3+ seconds to enter selection
• Cycle until desired LED color is displayed, then release to save
• Do not charge FLA batteries when in Lithium (blue) or AGM (white) modes
• Magenta constant mode supplies full rated load but is not for long-term storage

What electrical specs and installation format should I expect?

The PD9360V runs on standard 105–130 VAC 60 Hz and produces up to 1000 watts, delivering 60 amps of DC output. It’s designed as a deck‑mount converter for RV compartments and offers straightforward wiring for replacing older converters or integrating into a new build.

• Input: 105–130 VAC, 60 Hz, up to 1000 W
• Output: 13.6–14.7 VDC selectable, 60 A continuous
• Deck‑mount form factor for RV battery bays or cabinets
• LED status indicators for quick visual checks of mode and stage

Who is this for: The Inteli-Power PD9360V is aimed at RV owners, fleet managers and DIY converters who want a single, compact charger that adapts to different battery chemistries without swapping hardware. It’s especially useful if you expect to upgrade batteries (e.g., move to LiFePO4) or operate multiple battery types across rigs and want consistent, automated charging behavior and storage routines.
