TWTADE JQX-62F-2Z High-Power DPDT Relay AC 110V 80A — 2NO+2NC, 8-Terminal Panel Mount

This high-power relay from TWTADE combines a robust AC 110V coil with DPDT contacts and an 80A rating to handle demanding switching tasks in industrial and commercial equipment. Sized for panel and enclosure mounting, it includes eight screw terminals and comes with removable terminal connectors for quick wiring. Built from solid materials and rated for both 28V DC and 250V AC loads, the JQX-62F-2Z is a versatile option when reliable, high-current switching is needed.

How does this relay handle high-current loads safely?

The JQX-62F-2Z is engineered to manage up to 80A when switching suitable voltages, reducing heat buildup through its contact design and solid housing. Proper wiring and terminal connection are essential to maintain performance and avoid overheating.

• Rated load: 80A at 28V DC and up to 250V AC for alternating current applications.
• DPDT contact arrangement (2NO + 2NC) supports multiple circuit configurations.
• Eight terminals for secure connections and reduced contact resistance.
• Compact robust construction (approx. 85 x 65 x 65 mm) for enclosure mounting and airflow.

What connections and wiring options are available for installation?

Connections are made via eight screw terminals that accept standard ring or spade terminals; the package includes eight removable terminal connectors to simplify wiring. The DPDT layout lets you switch two independent circuits or create latching and interlock schemes when paired with appropriate control wiring.

• Coil input: AC 110V standard coil voltage for common control systems.
• Contact configuration: 2 normally open + 2 normally closed contacts for flexible control logic.
• Includes 8 terminal connectors for immediate installation without extra hardware.
• Terminal layout supports ring/spade connectors and secure screw fastening.

Where will this relay fit and how large is it?

The relay's footprint and height make it suitable for control panels, motor starters, HVAC systems, and other enclosed electrical assemblies where high current switching is required. Its moderate size balances current capacity with convenient mounting in constrained spaces.

• Approximate dimensions: 85 x 65 x 65 mm (3.3" x 2.5" x 2.5").
• Weight: about 320 g—sturdy but manageable for panel mounting.
• Eight-terminal arrangement keeps wiring organized inside enclosures.
• Durable housing shields internal components from incidental contact.

What comes in the box and what should I check before use?

The package includes the TWTADE JQX-62F-2Z relay plus eight terminal connectors to speed installation. Before powering the coil, verify control voltage, confirm load ratings, and ensure secure terminal fastening to prevent loose connections and excessive heating.

• Included: 1 x TWTADE JQX-62F-2Z high power relay and 8 x removable terminal connectors.
• Check coil supply: ensure a stable AC 110V control source.
• Confirm load type and voltage do not exceed 80A rating at specified voltages.
• Tighten all terminal screws and verify wiring polarity and contact arrangement.

Who is this for: The TWTADE JQX-62F-2Z is aimed at technicians, system integrators, and equipment builders who need a compact, high-current DPDT relay for industrial controls, motor circuits, HVAC systems, and commercial electrical installations. It suits projects where reliable switching at AC 110V coil control and substantial current handling are required, and where secure terminal connections and a standardized form factor simplify integration.
