Vgate vLinker MS Bluetooth OBD2 Scanner for iPhone Android Windows — Multi‑CAN Support, 12V/24V, High‑Speed 3Mbps

Designed for technicians and DIY drivers who need broader vehicle protocol coverage, the vLinker MS extends OBD2 scanning beyond standard CAN by adding support for HS-CAN, MS-CAN, SW-CAN, CH-CAN and LS-CAN. It works in both 12V and 24V vehicle networks, supports higher baud rates and longer frame communication, and pairs with many popular third-party apps so your phone, tablet or PC becomes a flexible car diagnostic tool.

Which vehicles and electrical systems will this adapter work with?

The vLinker MS is built to operate in OBD2-compliant vehicles that use CAN variants as well as in larger 24V systems, commonly found in trucks and commercial equipment. It detects and communicates with multiple CAN layers so it can access modules other adapters cannot.

• Compatible with 12V passenger cars and 24V commercial vehicles
• Supports GMLAN, MS-CAN, HS-CAN, SW-CAN, CH-CAN, LS-CAN
• Works with OBD2-compliant pinouts for universal connection

How fast and reliable is data transfer for live gauges and coding?

This adapter supports up to a 3 Mbps baud rate and can handle up to 4K OBD request bytes, enabling smoother live-graphing, quicker parameter polling, and reliable long-frame exchanges required by advanced modules. Faster throughput reduces lag when you monitor multiple PIDs or run programming sequences.

• High-speed 3 Mbps communication for rapid live data
• Supports long-frame messages for extended diagnostic commands
• Improved responsiveness for real-time gauges and logging

Will it drain my vehicle battery if left plugged in?

Battery Saver Technology gives the vLinker MS an automatic sleep/wake cycle with a low idle draw to prevent battery drain. It operates at roughly 28 mA during normal use and drops to as low as 3 mA when idle, then wakes again when a diagnostic session starts or the vehicle signals activity.

• Automatic sleep and wake-up functions reduce battery consumption
• Operating current ~28 mA; sleep current down to ~3 mA
• Safe for extended connection when monitoring or logging

Which apps and platforms can I use with the vLinker MS?

The adapter pairs with numerous third-party diagnostic apps across Android, iOS and Windows, turning your device into a full-featured scan tool. Many advanced apps are Android-first, so check app availability and compatibility for iPhone/iOS before purchase; firmware updates can be applied from phones or a Windows PC.

• Works with Car Scanner, Dr. Prius, JScan, Multiecuscan and more
• iOS app support varies—confirm with app developers
• Firmware upgrades supported via phone or Windows PC

Who is this for: The Vgate vLinker MS is aimed at automotive professionals, independent mechanics and informed DIYers who need extended CAN protocol coverage, reliable high-speed data for diagnostics and logging, plus the flexibility to use mobile and desktop apps. Choose this adapter if you require multi-CAN access, 12V/24V compatibility, and low-power operation for prolonged use.
