Vypart Washer Water Inlet Valve for Maytag Bravos MVWB765/MVWB835 – Compatible W11096267 W11165546, 4-Solenoid 120VAC

Vypart replacement washer water inlet valve (W11096267/W11165546 compatible) restores correct hot and cold water flow for top-load Maytag Bravos and related models.

If your Maytag Bravos or compatible top-load washer is filling slowly, leaking, showing LF/F8E1-style errors, or not filling at all, the water inlet valve is a common wear item. This Vypart valve is designed to match OEM electrical and hose connections for a straightforward swap on many Maytag, Whirlpool, Kenmore, and Cabrio models. It contains four solenoid-controlled ports to manage hot and cold fill circuits and is rated for standard 120VAC, 60Hz household power.

How do I know this valve is the right part for my washer?

Check your washer’s model and the OEM part numbers your machine lists. This Vypart valve is built to replace W11096267, W11165546 and several related numbers used across Maytag Bravos XL, commercial top-load, Whirlpool Cabrio, and Kenmore top-loading units. If your machine uses one of those references and has similar hose and connector layouts, this assembly is a compatible swap.

• Direct cross-references: W11096267, W11165546, W10599423, W10758828 and others.
• Fits many models: MVWB835 series, MVWB765 series, MVW7230/7232 series and more.
• Designed for top-load washers with four solenoid ports (hot/cold control).

What symptoms indicate the water inlet valve needs replacing?

Faulty valves commonly cause slow or no fill, persistent leaks, or electronic error codes related to water inlet faults. You may hear clicking from the valve without water flow, or find the washer displays LF, F8E1, or similar fill errors. Visual inspection can reveal water at the base of the valve assembly or damaged solenoid housings.

• Washer fails to fill or fills very slowly.
• Visible leaking around the inlet valve or hose connections.
• Error codes referencing water fill or inlet faults.

How difficult is installation and what tools are required?

Installation is a moderate DIY task that many homeowners can complete with basic tools. You’ll unplug the washer, shut off the water, remove the top panel, unplug connector harnesses and hoses from the old valve, remove mounting screws, and then reverse the steps to install the new assembly. If you’re comfortable manipulating appliance wiring and hoses, the swap typically takes under an hour.

• Turn off power and water first to avoid electrical shock and flooding.
• Tools: screwdriver set, pliers, and optionally a container for residual water.
• Follow wire harness layout and hose orientation exactly when reinstalling.

Will this valve solve all washer filling problems?

Replacing the inlet valve addresses mechanical and solenoid-related failures but won’t fix unrelated electrical or control-board issues. If the valve functions properly after installation and the washer still fails to fill, further diagnostics of pressure switches, timers, or the control board may be needed. Use this part when symptoms and tests point to a failed inlet assembly.

• Fixes solenoid failures, internal valve leaks, and many slow-fill issues.
• Not a solution for broken control boards or clogged inlet screens upstream.
• Test after installation to confirm the problem is resolved.

Who is this for: This Vypart water inlet valve is aimed at homeowners, repair technicians, and appliance service pros working on Maytag Bravos XL, Whirlpool Cabrio, and Kenmore top-load washers that use the listed OEM part numbers. It suits anyone seeking a like-for-like replacement to restore normal hot and cold water fills without replacing the entire washer.
