ZHENJUN Passenger Side Mirror Glass Replacement for BMW 5/6/7 Series (2009–2016) RH — Heated, Auto-Dimming with OE Backing Plate

This ZHENJUN mirror glass assembly is engineered to match the OE specifications for BMW chassis E60, F06, F07, F10, F13, F01 and F02 (2009–2016). Designed as a direct-fit replacement for part number 51-16-7-228-612 (RH), the unit brings power heating and automatic anti-glare functionality in a single plug-and-play lens with a robust ABS backing plate. It restores visibility and reduces nighttime glare while fitting securely into the original mirror housing.

Will this mirror work on my BMW 5/6/7 Series from 2009–2016?

Yes. The glass is manufactured to OE-style dimensions and fastening points for E60, F06, F07, F10, F13, F01 and F02 models of the BMW 5, 6 and 7 Series produced between 2009 and 2016. It is intended for the right (passenger) side and matches the referenced OE part number.

• Compatible chassis: E60, F06, F07, F10, F13, F01, F02
• Model years covered: 2009–2016
• Side: Right (passenger)
• OE reference: 51-16-7-228-612 (RH)

How do the heating and auto-dimming features operate?

The lens integrates a 4-pin electrical connector that combines heated glass and an auto-dimming element. When connected to the vehicle harness, heating reduces ice and condensation, while the anti-glare layer automatically darkens in response to bright rear lighting to cut down on eye strain.

• 4-pin connector: two pins for heating, two for anti-glare
• Vehicle voltage output: typically 1.25–1.4 V to the anti-glare circuit
• Plug-and-play: designed to mate with original factory plugs
• Reduces nighttime glare and speeds up defrosting

Is installation difficult and will the mirror stay secure at high speeds?

Installation is straightforward for users familiar with mirror replacement: remove the original lens, disconnect its wiring, align the new backing plate and plug in the connectors, then press the lens into the existing mount. The ABS backing plate and OE-style fastenings are engineered to hold the lens firmly even under highway speeds.

• Installation steps: remove old lens, disconnect wires, align plugs, press into place
• Mount construction: ABS backing plate rated for -40°C to 100°C
• Retention: OE-style clips secure lens at 65–80 MPH
• Material: alloy-reinforced plastic for durable flexibility

What build quality and durability can I expect?

The rear of the mirror uses a two-piece ABS support designed to clamp securely into the factory mirror housing and withstand wide temperature ranges. The glass is bonded to OE-style fasteners to minimize vibration and maintain optical alignment over time.

• Backing plate material: ABS, rated for extreme temperatures
• Durability features: alloy-reinforced plastic for toughness
• Fastening style: OE-style clips for long-term security
• Optical quality: anti-glare coating for clearer night vision

Who this is for: ZHENJUN’s RH passenger-side mirror glass replacement suits BMW owners and independent technicians who need a direct-fit, functionally complete spare that restores heating and auto-dimming capability without rewiring. Choose this part if you require OE-compatible mounting, reliable thermal and anti-glare performance, and a durable backing plate built for everyday driving conditions.
